Model: 29-3102-100
Brand:
Call us at 858-367-9733 and save 10%.The EasyOnePro is the first product that applies ndd "TrueFlow", "MolMass" and "UPG" simultaneously. This device is highly portable, self contained, instant point of care/bedside use with no warm up time. Includes an industrial standard embedded PC, Windows XP embedded operating system, which supports standard printer, network, security and peripheral device functions.
Materials Included
-2 E-cylinders
-1 regulator
-1 portable cart
-1 Portable color inkjet printer
-1 box of 50 spirettes
-1 box of 50 barriettes
Technical Specifications
Flow/Volume Measurement
Type: Ultrasound
Accuracy: Ã,± 2% or 0.050l
Resolution: Volume: > 1ml, Flow: 4ml / s
Range: Volume: Ã,± 12 l, Flow: Ã,± 16 l/s
Helium Analyzer
Type: Molar Mass
Accuracy: < 0.1 % He
Resolution: < 0.05% He
Range: 0 - 50 % He
Carbon Monoxide Analyzer
Type: NDIR
Accuracy: Ã,± 0.003 %
Resolution: 0.001 %
Range: 0 - 0.35 %
Mouth Pressure Sensor
Type: Differential Pressure
Accuracy: Ã,± 4 %
Resolution: 0.05mbar
Range: Ã,± 100mbar
Barometric Pressure Sensor
Type: Silicon solid state
Accuracy: Ã,± 7.5 %
Resolution: 1mbar
Range: 150 - 1150mbar
Case Temperature Sensor
Type: Solid state
Accuracy: Ã,± 1 Ã
Type: Ambient temperature
Accuracy: Ã,± 0.4 Ã
Type: Ambient humidity
Accuracy: +/- 4 %
Resolution: 1 %
Range: 0 - 100 %
Dimensions: 27 H x 33.5 W x 27 D cm.
Weight: < 8 kg
